Generally, it is used in residential premises when preserving as much space as possible is the priority.
Additional airborne sound isolation value for ZIPS Vector system is from 12 to 14 dB.
System | Material to be sound-insulated | Efficiency, dB | Total thickness, mm | Noises to be reduced | Super power and its application |
ZIPS Vector | Foam concrete, brick, tongue-and-groove block | ΔRw up to 12-14 dB | 53 | Talking, TV, radio | The thinnest panel of the ZIPS family. More often is used for sound-insulation of walls and partitions. |
ZIPS Modul | Brick, concrete | ΔRw = 16-18 dB | 83 | Loud talking, shouting, TV, dog barking, water noise | Effective system, suitable for solution of 80% of all household noise issues |
ZIPS Cinema | Concrete, brick | ΔRw = 19-20 dB | 133 | Loud talking, shouting, TV, dog barking, water noise, noise from a loud audio system or a home theater | The most effective sound-insulating system in the entire ZIPS range. When you use this system, it means that everything that can be done has been done. |
ZIPS III-Ultra | Foam concrete, brick, concrete | ΔRw = 16-18 dB | 55 | Loud talking, shouting, TV, dog barking, water noise | The ultimate system in terms of the thickness/efficiency ratio. Despite being thin, it ensures great additional sound insulation and is suitable for 80% of tasks. |
ZIPS-4 | Foam concrete, brick, concrete | ΔRw = 16-19 dB | 55-105 | Loud talking, shouting, TV, dog barking, water noise | Family flagship . This system is for those who value their time and money. It not only ensures top efficiency despite its lesser thickness, but also allows to level the surface using adjusting supports, thus avoiding wet processes. |
ZIPS Slim | Foam concrete, aerated concrete, tongue-and-groove block | ΔRw = 11 dB | 37.5 | Conversations, TV, radio | The thinnest panel of ZIPS family. It is used for sound insulation of inter-flat walls made of foam concrete with a thickness of < 200 mm |
Installation of the panel system ZIPS must be carried out in strict accordance with the installation manual.
Composition and description
ZIPS Vector sound-insulating panel system consists of 40 mm (1.6 in) thick ZIPS 4 sandwich panels and special 12.5 mm (0.5 in) thick finishing plasterboard sheets. The total thickness of the system is 52.5 mm (2 in).
ZIPS Vector sandwich panels are a combination of layers of moisture-resistant gypsum plasterboard and fiberglass plate. Each sandwich panel includes eight vibration insulating joints for installation on the surface.
Storage
ZIPS Vector panels must be stored in dry, enclosed premises, away from any precipitation.
The panels should be stacked horizontally on wooden pallets, boards or other padding materials to avoid sagging.
Achieves an impressive 14 dB reduction in impact noise (ΔLw). Enjoy peace knowing you won't bother your neighbors, and they won't bother you.
No Messy Concrete
This is a dry-fit installation—no cement, screeds, or "wet" processes required. It's cleaner, faster, and perfect for renovations.
Engineered for Noise
Each panel features eight specialized Sylomer® anti-vibration mounts. These mounts act as tiny shock absorbers, breaking the path of sound vibrations before they can travel through your floor structure.
Slim Profile
The complete installed system is just 53 mm thick (including the final top layer), minimizing the loss of ceiling height in your room.
The core technology lies in the 8 integrated Sylomer® elastomer supports. These patented supports decouple the soundproofing panel from your actual floor structure, ensuring that vibrations (the source of noise) are stopped right at the source, giving you maximum sound isolation performance.
